PATCH CORDS & MOLDED CABLE ASSEMBLIES
GENERAL CABLE GUIDE PHONE: 773 792-2700
* Please visit the product pages on our website for the most up-to-date product information
STANDARD CABLE GUIDE
FOR MOLDED CABLE ASSEMBLIES ON PAGE 253 THROUGH 259
Cable Type
W1000
W1000-1
W1000-2
W1021-1
W1021-1
W1013-1
W1013-2
W1032-1
W1032-2
W1041-1
W1041-2
W1065-2
W1072-1
W1230-1
W1230-4
W1230-5
W1243-2
W1033-1
W1033-2
W1096-2
Color
Beige
Gray
Black
Gray
Black
Gray
Black
Gray
Black
Gray
Black
Black
Gray
Gray
Beige
White
Black
Gray
Black
Black
Description
50 ? coax, plastic jacket over spiral shield with 22 AWG stranded center conductor;
.156" (3.96 mm) outside diameter. Average capacity 31 pF/feet, UL style 1354
2 conductor, plastic jacket over shield with 2, 22 AWG conductor; .20" (5.2 mm)
outside diameter. Average capacity 20 pF/feet between conductor; 55 pF/feet between
shorted conductor to shield; 32 pF/feet each conductor to shield, UL style 2092
2 conductor, plastic unshielded parallel with 2, 18 AWG stranded conductor;
.11" (2.8 mm) x .21" (5.3 mm) outside diameter, UL type SPT-1
48 ? coax, plastic jacket over spiral shield with 25 AWG stranded center
conductor; .11" (2.8 mm) outside diameter. Average capacity 35 pF/feet
2 conductor, plastic unshielded tandem cable with 2, 24 AWG stranded
conductor; .06" (1.5 mm) x .12" (2.9 mm)
50 ? coax, plastic jacket over braid shield with 26 AWG stranded center conductor;
.1" (2.5 mm) outside diameter. Average capacity 30 pF/feet, RG-174
2 conductor, twin coax, plastic jacket over 2 individually shielded 25 AWG parallel
conductor. Average capacity 36 pF/feet, recommended for headset applications
2 conductor,plastic unshielded with 2, 18 AWG stranded conductor;
.25" (6.4 mm) outside diameter, UL type SVT
75 ? coax, plastic jacket over shield with 27 AWG stranded center conductor;
.15" (3.8 mm) outside diameter. Average capacity 20.5 pG/feet, UL style 1354 or 1436
2 conductor, plastic unshielded parallel with 2, 20 AWG stranded conductor;
.10" (2.54 mm) x .19" (4.7 mm) outside diameter, UL style 2433
2 conductor, plastic unshielded parallel with 2, 22 AWG stranded conductor;
.08" (1.9 mm) x .15" (3.8 mm) outside diameter
Cable Code
A
B
K
D
Y
E
F
V
X
C
Z
See page 251 for Cable Assembly Termination vs. Cable Cross Reference Table.
DIMENSIONS ARE FOR REFERENCE ONLY
www.switchcraft.com
Inch
(mm)
? Registered trademark of Switchcraft, Inc.
Note: Contact your Switchcraft Representative for price and delivery
